Product Detail
Technical Parameter:
|
Model |
DV-2515 |
DV-3020 |
DV-4030 |
|
Metal Table Size(mm) |
408X308 |
458X358 |
458X558 |
|
Glass Table Size(mm) |
306X196 |
350X250 |
450X350 |
|
X,Y-axis Travel(mm) |
250X150 |
300X200 |
400X300 |
|
Z-axis Travel(mm) |
250 |
250 |
250 |
|
Resolution(mm) |
0.0005 |
0.0005 |
0.0005 |
|
X,Y-axis Accuracy(um) |
≤3+L/200 |
≤3+L/200 |
≤3+L/200 |
|
Measuring Software |
Quick Measuring |
Quick Measuring |
Quick Measuring |
|
Net Weight(kg) |
320 |
460 |
540 |
|
Dimensions(mm) |
926X612X1082 |
930X670X1100 |
1080X770X1110 |
|
Video System |
High Resolution Color CCD Camera ,0.7~4.5 Zoom Lens, Video Total Magnification:30X~230X(with 2X Additional lens, to Total Magnification440X), Object View:7~1.1mm 4-division LED adjustable Illuminator |
||
|
Power |
180V~260V(AC),50HZ |
||
Description:
1.Be Applied to Mechanical,Electronic ,Plastic Fields etc.
2.Fashionable Shape With Stable Ark Pillar Granite Design.
3.Adjustable 4-division LED Illuminator controled by panel or software
4.Obviously assistant laser position system
5.Powerful Measuring Software Quick Measuring Version
6.Function of Data Processing,Displaying,Input,Output,
