Technical Parameter:

Model	LTM-5013C Rotary Vertical Crockmeter
Rubbing Head	Dia.16mm
Vertical Pressure	1134g
Rotation	1.125turns
Tester Dimensions	250x150x250 mm(LxWxH)
Power Voltage	220/110 V 50/60 Hz 2 A
Tester Weight	11 Kg

Application:

Rotary Vertical Crockmeter, to determine the colour fastness of textiles to dry or wet rubbing particularly for printer fabrics.

Rotary crockmeter applies 1134 grams of pressure on a 16mm finger and rotate 1.125 turns clockwise then anti-clockwise.

The operating handle is however turned in one direction only.

Accessories:

AATCC rubbing clothing 1 box

Sand paper 2 (pcs)

Rings 2 (Pcs)

Standards:

AATCC 116, ISO 105 X16
